Cali Raised LED Transfer Case Skid Plate for 2007-2014 Toyota FJ Cruiser
Cali Raised LED Transfer Case Skid Plate for 2007-2014 Toyota FJ Cruiser
Of all the FJ Cruiser accessories that matter, underbody protection is the one you notice only when it is missing. And of everything hanging under an FJ, the transfer case is the one you least want to hit. A dented tank is a problem. A cracked transfer case housing is a recovery, a tow and a rebuild, usually a long way from anywhere.
This Cali Raised LED transfer case skid plate covers it. Choose 3/16 inch American steel or aluminum at checkout, finished in durable semi-gloss black powder coat. The included crossbar is always 3/16 steel regardless of which material you pick, because that is the component carrying the real structural load. It is 100% bolt-on with zero modification, using factory hardware plus Grade 8 hardware, and it is a universal fit across all 2007-2014 FJ Cruisers. Crafted by American welders. Two-year Cali Raised LED warranty.
The Crossbar Is Always Steel
This is the detail worth understanding before you pick a material, because it changes what the aluminum option actually is.
Whichever plate you choose, the included crossbar is made from 3/16 steel. Cali Raised does not offer it in aluminum, because the crossbar is the structural member doing the hard work while the plate is the shield.
What that means in practice: the aluminum option is not an all-aluminum setup. You get a steel backbone with an aluminum shield, which is a sensible hybrid rather than a compromise. The strength stays where it needs to be and the weight saving comes off the part where weight is just weight.
Steel or Aluminum?
You choose the plate material for this FJ Cruiser skid plate at checkout.
| Steel Plate | Aluminum Plate | |
|---|---|---|
| Thickness | 3/16" American steel | Aluminum |
| Crossbar | 3/16 steel on both | |
| Impact Behaviour | Takes repeated hits, dents rather than tears | Lighter, slides well, deforms more on a hard strike |
| Corrosion | Relies on the powder coat | Naturally corrosion resistant |
| Best For | Hard rock work, repeated contact | Overlanding, weight-conscious builds, salted roads |
Choose steel if you crawl rock regularly and expect repeated hard contact under the middle of the vehicle. Choose aluminum if you overland, watch weight, or live somewhere they salt the roads in winter. Either way the steel crossbar is doing the structural work.
Why the Transfer Case Specifically
Middle of the Vehicle
It sits where the chassis is highest off the ground but also where you high-centre on a ridge or a rut crown.
Not a Cheap Fix
A cracked housing means fluid loss, a tow and a rebuild. There is no limping home on a damaged transfer case.
No Factory Protection
The FJ leaves this area largely exposed. The factory cover underneath is not an impact plate.
High-centring is the scenario that catches people out. You are not hitting anything at speed, you are easing over a crest and the weight of the vehicle settles onto whatever is underneath the middle. A proper skid turns that into a scrape instead of a problem.
Bolt-On, With Grade 8 Hardware
The plate is 100% bolt-on with zero modification to the vehicle, using a combination of factory hardware and Grade 8 hardware.
Grade 8 is worth noting rather than skipping. It is a high-tensile fastener spec, and on a plate designed to absorb impacts the bolts holding it on carry the load too. Cheap hardware on a good skid is a poor trade.
It is also a universal fit across all 2007-2014 FJ Cruisers, so there is no trim or year variant to select. Cali Raised includes installation instructions, and there is an install video if you prefer to watch it done first.
Specifications
| Vehicle | 2007-2014 Toyota FJ Cruiser, universal fit across all years |
| Protects | Transfer case |
| Plate Material | 3/16" American steel or aluminum, chosen at checkout |
| Crossbar | 3/16 steel, included, on both material options |
| Finish | Durable semi-gloss black powder coat |
| Installation | 100% bolt-on, no drilling or modification |
| Hardware | Factory hardware plus Grade 8 hardware |
| Manufactured | USA, crafted by American welders |
| Warranty | 2 years, Cali Raised LED |
Pros
- An FJ Cruiser skid plate for the one component you genuinely cannot limp home without
- Choice of 3/16" American steel or aluminum plate
- Steel crossbar included on both options, so strength stays where it matters
- 100% bolt-on with zero modification to the vehicle
- Grade 8 hardware alongside factory fasteners
- Semi-gloss black powder coat for long-term corrosion resistance
- Universal fit across all 2007-2014 FJ Cruisers, no variant to choose
- Crafted by American welders, two-year warranty
Cons
- Cali Raised does not publish weights for either material option
- Aluminum plate thickness is not specified, only that the plate is aluminum
- Covers the transfer case only, so front and fuel tank need separate plates
- The aluminum option is not an all-aluminum setup, since the crossbar is steel
Frequently Asked Questions
If I choose aluminum, is the whole thing aluminum?
No. The included crossbar is always 3/16 steel regardless of which plate material you pick, because the crossbar is the structural member while the plate is the shield. So the aluminum option is a steel backbone with an aluminum shield. That is a sensible hybrid rather than a compromise: the strength stays where it is needed and the weight comes off where weight is just weight.
Steel or aluminum plate?
Steel at 3/16 inch handles repeated hard contact better, which suits regular rock work where the middle of the vehicle takes hits. Aluminum saves weight and resists corrosion naturally, which suits overlanding, payload-conscious builds and salted winter roads. The steel crossbar is included either way, so you are choosing the shield material rather than the structure.
Why is the transfer case worth protecting?
Because there is no limping home on a damaged one. A cracked housing means fluid loss, a tow and a rebuild. It also sits in the part of the vehicle that takes the weight when you high-centre on a ridge or a rut crown, which is not a high-speed impact but a slow settling of the whole vehicle onto whatever is underneath. A proper skid turns that into a scrape.
Will it fit my FJ?
This Toyota FJ Cruiser skid plate is a universal fit for all 2007-2014 models, so there is no year or trim variant to select. Installation is 100% bolt-on with no drilling or modification. Call us at 844-200-3979 if you are running other underbody modifications and want to check for clearance before ordering.
Does this cover the rest of the underbody?
No, this plate covers the transfer case only. A full underbody set also needs front and fuel tank protection, which are separate plates. If you are building out the whole underside, call us at 844-200-3979 and we will map out the set and talk through which material makes sense across the build rather than plate by plate.
